What the FAB with UMPK glide kit is made of
48 documented parts and 43 photos, from recovered wreckage and the reporting on it. Each part gives its marking, maker and country where known, and links the record it comes from. The system itself: FAB with UMPK glide kit.
Where the parts were made
- United States of America 15
- Altera Corporation (Intel), Analog Devices, Linear Technology Corporation (Analog Devices), Sipex Corporation, Texas Instruments, Maxim Integrated Products (Analog Devices), Intel Corporation, CTS Corporation, American Microsemiconductor
- People's Republic of China 10
- KST Digital Technology, MT Microsystems Co., Ltd., XLSEMI, YXC (Shenzhen Yangxing Technology Сo., Ltd), Yangzhou Yangjie Electronic Technology Co., Ltd.
- Russian Federation 7
- ANPP TEMP AVIA JSC, VNIIR-PROGRESS JSC, UPKB DETAIL JSC, SEVERNY PRESS JSC, NPO BASALT JSC, URALELEMENT JSC, АО Морион
- Switzerland 7
- U-blox, Axicom (TE Connectivity), STMicroelectronics
- Japan 2
- Din-Tek
Sources
- HUR War & Sanctions: Universal gliding and correction module extended range (UMPK-PD) · українською
- HUR War & Sanctions: UMPC · українською
- HUR War & Sanctions: UMPC №КН23-002-7876 · українською
- Open Source Munitions Portal — search its munition identification records
- Telegram, news and web reporting — each row names the post or article it comes from
Ukrainian pages read alongside the English: same items, markings and text.
Universal gliding and correction module extended range (UMPK-PD) record ↗
Photo: HUR War & Sanctions
Jammer-proof satellite navigation system "Kometa-M12"
Завадозахищена супутникова навігаційна система "Комета-М12"
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Platform-free inertial navigation system (BINS)
Безплатформенна інерціальна навігаційна система (БІНС)
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
UMPC record ↗
Glider control system (SMART)
- TE AXICOM
IMO6
12 VDC
Medium power relay (5-20A)
record ↗
- HJ404050
28К СМ74
CMOS logic chip (HE)
record ↗
- MAX490
ESA
103
RS-845/ RS-422 protocol converter chip
record ↗
- SIPEX SP 3243EUEA
2236L H41V04
RS-232 driver chip
record ↗
- XSEMI
XL4015E1
23418
Voltage stabiliser (step-down PWM DC voltage converter)
record ↗
UMPC №КН23-002-7876 record ↗
Jammer-proof navigation module "Kometa"
- 19981
M10050-KB
A0100A
08659164
2303A3
GNSS module MAX-M10S based on U-blox M10050-KB
record ↗
- SJ88948
Thermocompensating quartz generator
record ↗
-
FPGA ALTERA Cyclone V
record ↗
- LTM4613Y
LINEAR DC/DC converter with input: 5 -36V
record ↗
- LTM4615V
LINEAR Low-voltage DC/DC converter
record ↗
- EPCQ
Non-volatile memory
record ↗
Servo drive
Inertial measuring module "SMART"
- Inertial system
- STM32F411CE
Microcontroller
record ↗
- YXC
16.000
24207A
Quartz resonator 16 MHz
record ↗
- MT6AGCS
MMG (MEMS) Gyroscope
record ↗
- MSI313
2301-1156
Inertia module
record ↗
- Board of the SMART module
- BBZ
GP142
Diode
record ↗
- ATS8SASM
CTS172131
Clock oscillator
record ↗
- BC226
Transistor
record ↗
- SS54
Schottky diode
record ↗
- XLSEMI
XL4015-E1
Step-down module with current and voltage regulation
record ↗
- IMO6
Medium power relay
record ↗
- MAX 490 ESA
Transceiver
record ↗
- HJ 4050
Buffer
record ↗
From other sources
Phased antenna array (3D spatial geometry)
Telegram channel, Russian side:UAV Development (UAVDEV) record ↗
FAB-250 high-explosive aerial bomb
FAB-1500 high-explosive aerial bomb
FAB-3000 high-explosive aerial bomb
ODAB thermobaric aerial bomb
RBK-500 cluster bomb
Open questions
What has not been published about the FAB with UMPK glide kit, and where the available evidence points: measurements from published photos, the physics, the parts its relatives carry, and the trade in the parts themselves. An indication is not a confirmation. Each one shows how it was reached; last reviewed 2026-10-23.
Also not yet established
- Phased antenna array (3D spatial geometry): does recovered wreckage of the FAB with UMPK glide kit show it? — A teardown record from HUR or another official body listing it, or a photo of it in recovered wreckage.
- FAB-250 high-explosive aerial bomb: does recovered wreckage of the FAB with UMPK glide kit show it? — A teardown record from HUR or another official body listing it, or a photo of it in recovered wreckage.
Also reported
- Airframe — Power frame, nose fairing, folding wings, elevons and stabilisers, attached to the bomb with steel clamps; no tail replacement needed, unlike JDAM source
- Final assembly — JSC NPO Kurganpribor performs final assembly of UMPK-250 and UMPK-500 modules (HUR, via Militarnyi) source
- Jet engine (UMPB-5R) — Photos from October 2025 suggest a Chinese Swiwin SW800Pro-Y commercial turbojet on the jet-powered UMPB-5R source
Part records and photos: HUR War & Sanctions, Ukraine's Defence Intelligence database of foreign components found in Russian weapons, and the other sources named on each part. A marking, date code or country is given as the source records it.
