What the Su-34 is made of
13 documented parts and 11 photos, from recovered wreckage and the reporting on it. Each part gives its marking, maker and country where known, and links the record it comes from. The system itself: Su-34.
Where the parts were made
- Russian Federation 12
- ZASLON JSC, AP VOSKHOD JSC, NPP POLET JSC, GIDROMASH’IM. V.I. LUZYANIN NJSC, PO UOMZ JSC, SEGZ JSC, KNIRTI JSC, ODK-UMPO PJSC, OMKB – BRANCH OF PJSC ODK-SATURN, NPP ZVEZDA JSC, KB ELEKTROPRIBOR JSC, NPP AEROSILA JSC
Sources
- HUR War & Sanctions: Su-34 fighter-bomber · українською
- Open Source Munitions Portal — search its munition identification records
- Telegram, news and web reporting — each row names the post or article it comes from
Ukrainian pages read alongside the English: same items, markings and text.
Su-34 fighter-bomber
Compact airborne radar station with passive phased array antenna Sh-141-02
Малогабаритна бортова радіолокаційна станція з пасивною фазованою антенною решіткою Ш-141-02
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Laser-television targeting station "Platan"
Лазерно-телевізійна прицільна станція "Платан"
Photo: HUR War & Sanctions
BANO-7M-3L and BANO-7M-K air navigation lights
Бортові аеронавігаційні вогні БАНО-7М-3л, БАНО-7М-К
Multifunctional aviation radio-electronic warfare system "Khybina" (product L-175V-02)
Багатофункціональний авіаційний комплекс радіоелектронної боротьтби "Хибина" (виріб Л-175В-02)
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
TA14-130-35 auxiliary gas turbine engines
Допоміжні газотурбінні двигуни ТА14-130-35
Photo: HUR War & Sanctions
From other sources
AL-31F-M1 afterburning turbofan engine
Open questions
What has not been published about the Su-34, and where the available evidence points: measurements from published photos, the physics, the parts its relatives carry, and the trade in the parts themselves. An indication is not a confirmation. Each one shows how it was reached; last reviewed 2026-10-23.
Also not yet established
- AL-31F-M1 afterburning turbofan engine: does recovered wreckage of the Su-34 show it? — A teardown record from HUR or another official body listing it, or a photo of it in recovered wreckage.
Also reported
- Engines — Two Saturn AL-31FM1 afterburning turbofans, 132 kN each with afterburner source
- Radar — V004 passive electronically scanned array radar source
- Radar antenna repair — Kotlin-Novator JSC repairs antennas for the onboard radar, per Ukrainian military intelligence (HUR); one of 79 enterprises HUR links to Su-34 production, about a third of them unsanctioned source
- Electronic warfare — Khibiny self-protection suite fitted as standard; KNIRTI's pod-mounted Khibini-2 delivered to the 47th Bomber Aviation Regiment from 2019, which took on more than 30 pods source
- Radar warning receiver — L150 Pastel radar warning receiver source
- Short-range radio navigation — Onboard RSBN-85V equipment and other navigation elements made by Navigator JSC (HUR, March 2026) source
- Onboard power supply — Power-supply systems from OKB Zenit JSC (HUR, March 2026) source
- Airframe materials — Titanium alloy products supplied through the trading arm of VSMPO-Avisma (HUR, March 2026) source
- Ejection seats — K-36DM ejection seats, built, repaired and modernised by Avitek in Kirov, a plant hit by a Ukrainian Flamingo missile in July 2026 source
Part records and photos: HUR War & Sanctions, Ukraine's Defence Intelligence database of foreign components found in Russian weapons, and the other sources named on each part. A marking, date code or country is given as the source records it.
